Description
Our Stage 2 Master Overhaul Kit is a great match for Max Hp Daily Drivers and Light towing applications, This kit will increase. Up to 70+Hp & 150+ ft lbs over a factory engine, Faster turbo spool and lower egts! Works great with single Non VGT turbo kits, custom tuning is not required but highly suggested.
- 6.4 Ford Power Stroke Diesel 2007-2010
- Stage 2 Master Over Haul Kit
- Ceramic Coated/Fly-cut & De-lipped Pistons
- Callies Enduro Stage 2 billet Camshaft (No Core Charge)
- Completely redesigned cam profile to reduce cam and lifter failures, Smooth Lobe Ramp Rate Technology
- One piece Billet Push rods
- Stage 1 High Rev 100lb Valve springs
- Fits any 6.4L Ford Power Stroke Diesel 2007-2010.
- 8-New Mahle International Maxxforce 7 HD 6.4L Pistons
- .STD-.010-.020-.030-.040 bore sizing available.
- Moly piston skirt coating.
- 8-DLC coated wrist pins.
- 16-pin locks.
- 8-ring sets.
- BEARINGS:
- Cleveite rod & main bearings (STD-.010-.020)
- CAM BEARINGS: .STD size
- LIFTERS: 16-HD USA made lifter set.
- CAMSHAFT: Kit Includes CALLIES Billet Stage 2 street/towing custom grind cam 70+HP
(works with factory tune & aftermarket tunes) - FREE T-Shirt Included, please select your size before check out.
We also offer Colt & RCD Billet Camshafts as an option
Gasket & Seals Set Includes: 4-oil pan, 1-oil filter, 1-misc o-ring, 1-timing cover, 1-oil pump inlet, 1-EGR valve, 1-oil manifold, 1-misc washer, 2-cylinder head,1-crank case cover, 4-cylinder head plug, 2- EGR cooler, 1-EGR valve, 16- fuel injection grommet, 8-fuel injection o-ring, 8- injection nozzle washer, 13- intake manifold, 3- oil cooler, 1-oil cooler o-ring, 1-thermostat, 2-throttle body, 3-turbo air fitting, 4-turbo oil drain, 4- valve cover, 20-valve cover grommet, 1-water outlet, 2-exhaust manifold, 6-exhaust pipe, 1-crankshaft cover, 1-timing cover, 1-rear main seal, 2-valve covers, 32- valve steam seal, 8-fuel injection lines.
Please spec sizing of pistons and bearings needed when ordering
Kits usually ship with in 3-5 business days depending on stock.
Additional information
| Weight | 70 lbs |
|---|---|
| Dimensions | 24 × 12 × 12 in |
| Piston Size | |
| Rod Bearing Size | |
| Camshaft Options | Callies Stage 2 Cam (+$0.00), Colt Stage 2 Cam (+$199.99), RCD Stage 2 Cam (+$199.99) |
| Mill Top Options | .Std Compression Height, Mill .010 off the top, Mill .020 off the top, Mill .030 off the top |
| Main Bearing Size | |
| upc |
- 224-3666, 224-3851, 224-3851WR, 224-3891, 42097, 6.4L Ford Power stroke pushrod set, 6.4L Ford Powerstroke billet cam shaft, 6.4L Ford Powerstroke diesel engine parts, 6.4L Ford Powerstroke fly cut piston set, 6.4L power stroke billet pushrod set, 6.4L Power stroke Diesel ceramic coated piston set, 6.4L power stroke diesel engine overhaul kit, 6.4L power stroke diesel engine rebuild kit, 6.4L Power stroke diesel replacement cam, 6.4L Power Stroke Diesel replacement Camshaft, 6.4L power stroke diesel stage 2 billet camshaft, 6.4l POWER STROKE ENGINE OVERHAUL, 6.4L powerstroke diesel, 6.4L Powerstroke Diesel cnc machined piston set, 6.4L Powerstroke Diesel engine kit, 6.4L powerstroke diesel lifter set, 6.4L powerstroke Super Duty, 789-1007, CB-1869P, CS54657, Engine Parts, Engine Rebuild Kit, Ford, Ford 6.4L Powerstroke diesel, HS54657, MS-2269P, Power Stroke replacement lifter set, Powerstroke Cam bearing set
